VM7 railing

The VM7 metal railing is a pedestrian containment system. It is installed along the edge of pavements on roads, streets, edges of bridges, and other grade-separated crossings in roadway or railway infrastructure.

It is an essential element for pedestrian safety on freely accessible operational railway tracks. It does not ensure vehicle containment.

Reference: 5769
Weight: 17 kg/m
Documentation:
Availability: Consult


Share

Features

  • Modular railing with deployé metal mesh baseboard.
  • Dovetail modules ensure handrail continuity.
  • Expansion joints are included in the design.
  • Special construction for sections on bends and curves (using a polygon) and on slopes.
  • Possibility of producing any module length.


Installation

  • Structure attachment by welding to the plate previously embedded into the concrete.
  • Structure attachment using a base plate secured with mechanical or chemical bolts in accordance with Standard EN 85-239-91 “Railings. Anchorage features, supply and installation conditions”.

Calculation note on request.


Surface treatment

GALVANISED: Hot dip galvanising anti-corrosion treatment according to EN 1461.

POWDER COATED: Protection using polyester powder coating, applying the QUALISTEELCOAT process based on Standard EN12944 according to the RAL colour requested.

ACQPA powder coated option.

DUPLEX SYSTEM: Hot dip galvanising + powder coating.


Technical Information

Geometric Characteristics

  • Height (mm): 1100 - 1300 - 1500
  • Distance Between Posts (mm): 1500 - 2000

Composition

  • Material: STEEL
  • Filler Type: MESH
  • Supporting Element: ANCHOR PLATE
  • Weight (kg/m): 17
